Integrity Platinum 104 Point Inspection
I. Road Test
1. Cold Engine start-up
2. Engine Operation warm-up
3. Engine at normal operating temperature
4. Brake and parking brake operation
5. Active seat belt test
6. Clutch and transmission operation
7. Overdrive operation
8. Steering operation and off center
9. Front and alignment
10. Tilt steering wheel operation
11. Transfer case operation (4-wheel drive only)
12. Windshield wiper and washer operation at all speeds; wiper blade conditions
13. Speedometer and odometer operation
14. Cruise control operation, including resume
15. Heater and air conditioning operation
16. Abnormal noises and vibrations
17. Squeaks and rattles
II. Frame and Structure
18. Frame Check
19. Body surface, lower body, and under damage requiring body shop repair
20. Tire defect and damage ; 5/23" minimum tread depth; tire pressure; same size/load/speed rating as OEM
21. Drive shaft, joints, CVs, and boots
22. Struts/shock absorbers leaks and wear
23. Exhaust system leads and damage, including catalytic converter
24. Fuel, oil, coolant, or other fluid leaks
Â
Mechanical Certification
          Â
           III. Under Hood
25. Under hood labels and decals
26. Air filter
27. Battery cables and mount
28. Coolant conditions ____F and test
29. Under Hood fluid levels, including transmission and transfer case fluids
30. Drive belts and hoses
31. Air conditioning levels; check at sight glass
IV. Functional and Walk-Around
32. Warning lights (including air bag), gauges and horn
33. Headlights, instrument lights, turn signals, flashers, brake lights, side marker lights, taillights, backup lights, and license plate light
34. Inside and outside rearview mirror operation adjustment and condition.
35. Glass free of cracks, stars, and large chips.
36. Dome, courtesy, map, and sun visor lights
37. Window Operation
38. Sunroof or convertible top operation
39. Audio system and clock (set if required)
40. Factory-installed alarm system functional
41. Cigarette lighter operation and power outlets
42. Headliner; sun visors; dash pad; upholstery; console; cup holders/trim panels/carpets
43. Truck bed; bed liner; tailgate; rear bumper
44. Door and door key/lock operation, including rear deck on wagons; child safety door locks are in normal off position
45. Seats and seat belt operation for every position
46. Rear defogger; check with test lights
47. Headlights aim (inspection only)
48. Trunk light and trunk trim appearance
49. Hood, trunk, and fuel filter door latches
50. Spare tire pressure; jack and tire wrench match vehicle and work properly (including wheel lock)
51. Front license plate bracket
V. Mechanical
52. Wheels/Tires all match
53. Pull four wheels and check brakes for minimum 3mm remaining wear on pads; inspect rotors/drums for minimum thickness
54. Differential oil level
55. Engine oil and filter changed using quality replacement parts
56. Confirm tires have 5/23 or more
VI. Non-Factory Equipment
57. Factory air intake
58. PCM at factory settings
59. Vehicle suspension altered
60. Oversized tires installed
Â
Appearance Certification
          Â
           VII. Step 1: Exterior Cleaning
61. Wet body and fenders
62. Clean following areas using pressure washer
· Engine compartment
· Door jambs and behind gas filler door
· Tries and fender walls
· Wheels
· Bumpers and lower body below molds
· Spare tire-removed from trunk
63. Wash entire body and rinse thoroughly
64. Spray in an "H" pattern over engine compartment
65. Clean all exterior surfaces; dry door jambs with clean towel
Â
66. Is engine compartment dirt free and dressed?
67. Are wheels free of dirt and brake dust?
VIII. Step 2: Interior Cleaning
68. Dry brush carpets
69. Use compressed air to blow dirt from cracks, crevices, and between seats
70. Vacuum interior, ashtrays, glove box, trunk, carpet, and all trunk compartments
71. Clean all vinyl surfaces
72. Clean headliners, sun visors, ashtrays, and glove box with cleaner applied directly to towel
73. Dress all vinyl areas except gas and brake pedals and steering wheel (no shiny surfaces)
74. Clean interior windows using two towels; remove unnecessary decals
75. Pre-spot trouble areas on carpet, seats, door trim, and trunk carpet
76. Clean carpet, seats, door trim, and trunk carpet (if needed); use Clean HD Shampoo
77. Clean and condition leather surfaces as required
78. Reinstall spare tire and tighten down all equipment.
79. Is interior vacuumed and crevices cleaned?
80. Are carpets and seats free of strains and dirt?
IX. Step 3: Compounding, Polishing, Waxing
81. Buff exterior surfaces above body side moldings as needed
82. Cover wiper blades/arms using towels and protect high edges using masking tape
83. Compound surfaces to remove heady oxidation or heavy scratches as needed
84. Polish surfaces to remove moderate/light oxidation or fine scratches
85. Wax surfaces
86. Remove any dust or residue; use towel and detail brush to clean all jambs, cracks, and crevices
87. Clean exterior glass using two towels
Â
88. Is paint free of swirl marks
89. Do polished surfaces meet the detailer's certification standards?
X. Step 4: Exterior Dressing
90. Re-inspect for any remaining tar and road residue
91. Dress fender walls
92. Dress tires; remove excess with towel
93. Dress rubber moldings, window trim, and door and trunk gaskets
94. Dress badly weathered and faded black bumpers
95. Is body free of tar, road oil, and dirt?
XI. Step 5: Inspection by Detail Manager
96. Interior is completely odor free use Ozone Machine to correct
97. Exterior surfaces meets certification standards
98. Buffing dust and residue have been removed wheels are free of dirt and brake dust all interior cracks and crevices are clean
99. Glass is free of dirt and streaks
100. Body is reasonably free of dents and dings
101. Paint is reasonably free of chips and scratches
102. Interior is free of rips and tears
103. Bumpers are reasonably free of cuts and scratches
104. Glass is free of cracks, chips, and other defects
